InPower VCMS-PM1-SPC63 Power Distribution Module

InPower VCMS-PM1-SPC63 Power Module - Stand Alone

Your Price: $175.00

InPower VCMS-PM1-SPC63 Power Module - Stand Alone

The VCMS-PM1 is a six output, four input, control module used within the VCMS Switching System for controlling 12V auxiliary devices. The four inputs are programmable for pull up, or pull down TRUE operation. The six outputs are rated at 12V 15 amps each with the total module current rated at a maximum of 60 amps. Outputs incorporate over-current and short-circuit automatic fault detection.
Master and slave configurations available. All connections are .250 inch male faston blade terminals.

All outputs over-current protected
60 amp maximum rating per module
Four programmable digital inputs provided
DC voltage sense available on Mod 6
Modular and expandable design
Custom programming to provide for output to latching, flash, time on, time off, delay, etc.

Part Number: IP-VCMS-PM1-SPC63
